HIWIN HGH,HGW,EGH,EGW,EGN,MGW,HGR,EGR,HGL Series Linear Guide Hiwin linear guideway HG series supply
guides and rails provide a smooth, precision, guiding surface on which the rolling element of a linear bearing rides. They are an integral part of linear bearings, typically ordered separately from the rolling element component. They must exhibit this in terms of speed, temperature stability, accuracy and noise levels. Our linear guide available in several sizes to accommodate loads of all types, from light to heavy, and offer suitable for use in numerous applications, such as machine design requiring incorporation of linear guide products into the machine structure. We produce a complete range of linear guide designed to satisfy the most demanding requirements.
HG series linear guideways are designed with load capacity and rigidity higher than other similar products with circular-arc groove and structure optimization. It features equal load ratings in the radial,reverse radial and lateral directions, and self-aligning to absorb installation-error. Thus,HIWIN HG series linear guideways can achieve a long life with high speed, high accuracy and smooth linear motion.
All Models of Hiwin Linear Guideway we can provide:
HGH15, 20, 25, 30, 35, 45, 55, 65 CA/HA;
HGW15, 20, 25, 30, 35, 45, 55, 65 CA/HA/CB/HB/CC/HC;
HGL15, 20, 25, 30, 35, 45, 55, 65 CA/HA/CB/HB;
HGR 15 20 25 30 35 45 55 65 T
EGH15, 20, 25, 30 35 SA/CA;
EGW15, 20, 25, 30 35 SA/CA/SB/CB
EGR 15 30 U
EGR 15 20 25 30 T
MGW7, 9, 12, 15 C/H;
MGN7, 9, 12, 15 C/H;
RGW 25 30 35 45 55 65 CC/HC
RGR 25 30 35 45 65 T
QHH 15 20 25 30 35 CA/HA
QHW 15 20 25 30 35 CA/HA /CB/HB/CC/HC
(Other series are also available);
About Hiwin linear guideway rail Length:
| Rail length:40mm-4000mm | ||||
| Type | Model | Height (mm) |
Rail length | |
| 4 rows types |
Square | HGH | 28→90 | 100mm→4000mm |
| Flange | HGW | 24→90 | 100mm→4000mm | |
| Square | EGH | 24→42 | 100mm→4000mm | |
| Flange | EGW | 24→42 | 100mm→4000mm | |
| 2 rows types |
Narrow | MGN | 8→16 | 40mm→1200mm |
| Wide | MGW | 9→16 | 50mm→1000mm | |
Application of Hiwin Linear Guideway:
When you don't know how to choose hiwin linear guideways:
HG series--Grinding,milling,and drilling machine,lathe,machine center
EG series--Automatic equipment,high speed transfer device,semiconductor equipment,wood cutting machine
,precision measure equipment
QE/QH series--precision measure equipment,semiconductor equipment,antomatic equipment, laser marking
machine,can be widely applied in high-tech industry required high speed,low noise,low dust generation.
WE series--Automatic device,transportation device,precision measure equipment,semiconductor equipment,
blow moulding machine, single axis robot-robotics.
MGN/MGW series--Miniature device,semiconductor equipment,medical equipment
RG series--CNC machining centers,heavy duty cutting machines,CNC grinding machines,injection molding
machines,electric discharge machines,wire cutting machines,plano millers
Model Number of HG series linear guideways:
