Name: 5212C3 Double Row Angular Contact Ball Bearing For Mechanical Parts Engine Parts
Brand: Wuxi Guangqiang Bearing Trade Co.,Ltd
SKU: 5212C3
Price: Negotiable USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: 5212C3

ID: 60 Mm

OD: 110 Mm

Load Center: 65.5 Mm

Type: Angular Contact Ball Bearing

Material: High Carbon Chrome Steel

Fillet Radius: 1.5 Mm

Row Type Fill Slot: Double-Row Non-Fill Slot

Highlight:

5212C3 Ball Bearing

Angular Contact Double Row Ball Bearing

Mechanical Parts Ball Bearing

Basic Infomation

Place of Origin: Japan

Brand Name: NTN

Certification: ISO90001

Model Number: 5212C3

Payment & Shipping Terms

Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing

Delivery Time: 3 working days after received your payment

Payment Terms: T/T or western Union or PayPal

Supply Ability: 3,000pcs per month

Gallery

5212C3 Double Row Angular Contact Ball Bearing For Mechanical Parts Engine Parts

Product Description

High quality Ball Bearing 5212C3 Double Row Angular Contact Ball Bearing for Mechanical Parts Engine Parts Bearing

Bore Type

Straight
Bore Diameter
Outside Diameter
Overall Width
Closure Type

Open
Snap Ring Included

Without Snap Ring
Contact Angle

25 °
Bearing Material

High Carbon Chrome Steel
Bearing Type

Angular Contact Bearings
Cage Material

Steel
Cage Type

Pressed
Configuration

Two
Country of Origin

JP
Description

5212C3 BALL BRG
Fillet Radius

1.5 mm
Finish Coating

Uncoated
Harmonization Code

8482.10.5028
Inner Ring Width

1.4370 in, 36.500 mm
Internal Clearance

C3
Manufacturer Product Page

Click here
Manufacturer Upc Number

4547359538168
Max Rpm

5000 rpm
Precision Rating

Class 0
Radial Dynamic Load Capacity

69000 N
Radial Static Load Capacity

62000 N
Row Type Fill Slot

Double-Row Non-Fill Slot
Series

52
Type Of Bearing

Angular Contact Bearing
Weight

2.76 lbs
Product Type

Angular Contact Bearings

6. We also supply following bearings:

Designation	Dimensions (mm)			mass
	d(mm)	D(mm)	B(mm)	KG
7221 BEP	105	190	36	3.82
7321 BECAM	105	225	49	9.12
7321 BECBM	105	225	49	9.12
7321 BECBP	105	225	49	8.46
7321 BEGAM	105	225	49	9.12
7321 BEP	105	225	49	8.46
7222 BECBM	110	200	38	4.95
7222 BECBP	110	200	38	4.6
7222 BECBY	110	200	38	4.75
7222 BECCM	110	200	38	4.95
7222 BEGAF	110	200	38	4.95
7222 BEGBF	110	200	38	4.95
7222 BEM	110	200	38	4.95
7222 BEP	110	200	38	4.6
7322 BECBM	110	240	50	10.7
7322 BECBP	110	240	50	9.69
7322 BECBY	110	240	50	9.69
7322 BECCM	110	240	50	10.7
7322 BEGAM	110	240	50	10.7
7322 BEGBM	110	240	50	10.7
7322 BEM	110	240	50	10.7
7322 BEP	110	240	50	9.69
7322 BEY	110	240	50	9.69
7024 BGM	120	180	28	2.4
7224 BCBM	120	215	40	5.89
7224 BGAM	120	215	40	5.89
7224 BM	120	215	40	5.89
7324 BCBM	120	260	55	13.8
7324 BGBM	120	260	55	13.8
ALS 40 ABM	127	228.6	34.925	6.1
7226 BCBM	130	230	40	6.76
7226 BGAM	130	230	40	6.76
7226 BM	130	230	40	6.76
7326 BCBM	130	280	58	17.1
7326 BM	130	280	58	17.1
7028 BGM	140	210	33	3.85
7228 BCBM	140	250	42	8.83
7228 BM	140	250	42	8.83
7328 BCBM	140	300	62	21.3
7030 BGM	150	225	35	4.7
7230 BCBM	150	270	45	10.8
7230 BGAM	150	270	45	10.8
7330 BCBM	150	320	65	25
7232 BCBM	160	290	48	13.6
7332 BCBM	160	340	68	30.3
7234 BCBM	170	310	52	16.7
7334 BCBM	170	360	72	34.6
7036 BGM	180	280	46	10
7236 BCAM	180	320	52	17.6
7236 BCBM	180	320	52	17.6
